SPECIFICATIONS

Brand Name: ZHANGU

Origin: Mainland China

Maximum Torque(Nm): 20-40Nm

Wheelbase: 1000-1400mm

Brake System: Front drum+Rear disc

Minimum Grand Clearance: 150-200mm

Tire Size: 10''

Curb Weight: 200-300kg

Dimension: 180*116*115cm

Maximum Speed: 50-75Km/h

Driving Type: 2WD

Payload Capacity: 200-300kg

Differential Lock: Unequipped

Charge Time(h): 7-9h

Grade Ability: 15-20°

Driving Mileage: 50-70km

Transmission System: Shaft Drive

Power: > 1000W

Voltage: > 60V

Transmission Type: Automatic

Brand Name: Zhenglong

Place of Origin: Zhejiang, China

Charge time ( H ): 6-8

Charging requirements: AC80-240V 50-60Hz 78V/MAX5A

Brake type: Front Double Drum /Rear Double disc brakes

Front Tire size: 21X7-10

Rear Tire size: 22X10-10

N.W./G.W.(kg): 245/270

Max speed: 55km/H

One time charge mileage: 40-55km

Controller specifications: 72V/3000W

Rated speed: 4200

Product Description
